How the DOM Really Works
Let's start this new chapter or section by learning how the DOM really works behind the scenes and, more specifically, how the DOM is organized internally. This will make it easier for us to understand everything else that's going to follow in this section.
Let's start by remembering what we already know about the DOM:
Now, in the DOM, there are different types of nodes. For example, some nodes are HTML elements but others are just text, remember? And this is really important to understand because, all these DOM methods and properties are organized into these different types of objects. Let's now take a look at how the DOM API is organized behind the scenes.
First, every single node in the DOM tree is of the type
Now that we know that there are different types of nodes, how should these be represented? Well, the above node type has a couple of child types, which are:
Document. So whenever there is a text inside any element, we already know that it gets it's own node of type
Text. And the same actually happens for HTML comments, because the rule says everything that in the HTML document has to go into the DOM as well.
For the element itself, there is the
Element node type. This type of node gives each HTML element access to a ton of useful methods and properties. For example,
So, again, each element will be represented internally as an object. Just to make this complete, the element node type has internally an
HTMLElement child type, which is the base type for all HTML elements. In other words, the
HTMLElement type has one child type for each HTML element. For example,
HTMLDivElement etc. That's important because, each of these HTML elements can have different unique properties and methods. For example, the
HTMLButtonElement has a
disabled property, which is not available on the
HTMLDivElement type. Hence the DOM needs a way of storing these different attributes, and therefore, different types of HTML elements were created in the DOM API.
Just to make sure we are all on the same page, this diagram is NOT a DOM tree. It is NOT the representation of any HTML document. It is just how different types of nodes are represented behind the scenes in the DOM API.
With that being said, now comes the most important part. What makes all of this work is something called Inheritance. The question you might now ask is: what is inheritance? Well, inheritance means that all child types will also have access to the methods and properties of all their parent node types. For example, an
HTMLElement will have access to all the methods and properties of the
Element type, like
classList etc. Besides that, it will also have access to all the methods and properties of the
Node type, because that is also its parent type.
We can thinks of this as if the
HTMLButtonElement for example is also an element, and also a node.
Let's now talk about the
Document node type. So,
document which we use all the time in DOM manipulation is in fact just another type of node. It contains important methods such as
getElementById. And on the below image note how
querySelector is available on both the
Element types. So keep this in mind because it's going to be important later on.
We are now left with one final missing piece here 😉. Because the DOM API needs a way of allowing all the node types to listen to events. And remember, we usually listen to events by calling the
addEventListener method on an element or the document. So, why does that actually work? Well, it's because there is a special node type called
EventTarget, which is a parent to both the
With this and thanks to inheritance, we can call
addEventListener on every single type of node in the DOM API. Because all elements as well as
Window, and even
Comment, will inherit this method. Hence, we will be able to use
addEventListener on all of them just as if it was their own method.
To be clear, we never manually create an
EventTarget object. It is just an abstract type that we do not use in practice. This happens behind the scenes to make all the functionality work as we expect it to.
To finish this lecture, in a nutshell, this is how the DOM API works, and is structured behind the scenes. If you even want to go deeper, you can check out the MDN documentation which is really fascinating.
